Hikvision 4 Channel Turbo HD DVR

SKU SMT00010
N25 000.00
In stock
1
Product Details

Hikvision 4 Channel Turbo HD DVR is a 4 channel Analog DVR capable of recording upto 4 AHD/TVI/CVI/Analog cameras at a time. This is a special product that is cross compatible with other manufacturers. Also available at Sterling Magna Technologies office at Ajah, off Lekki Epe Expressway, Lagos state, Nigeria.

Video/Audio Input
Audio Input:1-ch
Video Compression:H.264,H.264+
Analog Video Input:4-ch
Analog and HD-TVI video input:1080p25, 1080p30, 720p25, 720p30
IP Video Input:1-ch
Audio Compression:G.711u
Two-way Audio:1-ch RCA(2.0Vp-p, 1kΩ)
Video/Audio Output
HDMI/VGA Output:1920 × 1080 / 60 Hz,1280 × 1024 / 60 Hz, 1280 × 720 / 60 Hz, 1024 × 768 / 60 Hz
Encoding resolution:When 1080p lite mode not enabled: 720p/WD1/4CIF/VGA/CIF
When 1080p lite mode enabled: 1080p lite/HD 720p lite/WD1/4CIF/VGA/CIF
Frame Rate:Main stream:
When 1080p lite mode enabled:
1080p lite/HD 720p lite/WD1/4CIF/VGA@12fps; CIF@25fps (P)/30fps (N)
When 1080p lite mode not enabled:
For 720p stream access:
720p/WD1/4CIF/VGA@12fps; CIF@25fps (P)/30fps (N)
For SD stream access:
WD1/4CIF/VGA/CIF@25fps (P)/30fps (N)
Sub-stream:
CIF/QVGA/QCIF@25fps (P)/30fps (N)
Video Bit Rate:32 Kbps ~ 4 Mbps
Stream Type:Video/Video&Audio
Audio Output:1-ch RCA(Linear, 1kΩ)
Audio Bit Rate:64kbps
Dual Stream:Support
Network management
Remote connections:32
Network protocols:TCP/IP, PPPoE, DHCP, Hik-Connect, DNS, DDNS, NTP, SADP, SMTP, NFS, iSCSI, UPnP™, HTTPS
Hard Disk Driver
Interface Type:1 SATA Interface
Capacity:Up to 6 TB capacity for each disk
External Interface
USB Interface:2 USB 2.0 Interfaces
General
Power Supply:12VDC
Consumption:≤ 8 W
Working Temperature:-10 ºC to +55 ºC (14 ºF to 131 ºF)
Working Humidity:10% to 90%
Dimensions:260 × 222 × 45 mm (10.2 × 8.7 × 1.8 inch)
Weight:≤ 1 kg (2.2 lb)
